进口化工离心泵原理特点及品牌（图）

进口化工离心泵是单级单吸悬臂式离心泵，其标记、额定性能点和尺寸等效果采用国际标准IS02858-1975（E），是一种用以取代F型耐腐蚀泵更新换代的节能产品，主要供吸送清水及物理化学性质类似水不含固体颗粒的液体。广泛用于工农业城市排水、消防供水等。供输送20℃～105℃的腐蚀性介质或物理、化学性能类似于水的介质。

产品特点

德国托马斯(Thomas)化工离心泵具有水利性能布局合理、可靠，体积小，质量轻，抗汽蚀性能好，电耗低，使用检修方便，工作效率高等优点。该泵为卧式结构，其结构设计基本能满足所有管道安装。

性能范围

流量Q：6.3～400m3/h

扬程H：5～132m

转速n：2900、1450r/min

配带功率：0.55～110KW

进口直径：50～200mm

最高工作压力：1.6Mpa

使用条件

化工离心泵的最高工作设计压力为1.6兆帕。介质温度不高于80℃。需要时采用双端面密封冷却装置，可输送介质温度为20℃～+280℃。

注：用户可根据被输送介质的腐蚀性程度对泵的过流部分主要零件选用不同材料。

Chemical centrifugal pump is a single-stage single-suction cantilever centrifugal pump, its mark, rated performance point and size and other effects using the international standard IS02858-1975 (E), is a replacement F-type corrosion-resistant pump replacement energy-saving products, Mainly for the delivery of water and physical and chemical properties similar to the water does not contain solid particles of liquid. Widely used in industrial and agricultural city drainage, fire water supply. For transport 20 ℃ ~ 105 ℃ corrosive medium or physical, chemical properties similar to the water medium.

Features

Germany Thomas (Thomas) chemical centrifugal pump with water performance layout is reasonable, reliable, small size, light weight, good anti-cavitation performance, low power consumption, easy maintenance, high efficiency. The pump is a horizontal structure, its structural design can basically meet all the pipeline installation.

Performance range

Flow Q: 6.3 ~ 400m3 / h

Head H: 5 ~ 132m

Speed n: 2900,1450r / min

With power: 0.55 ~ 110KW

Import diameter: 50 ~ 200mm

Maximum working pressure: 1.6Mpa

Conditions of Use

The maximum working pressure of the chemical centrifugal pump is 1.6 MPa. Medium temperature is not higher than 80 ℃. If necessary, use double-ended sealing cooling device, can transport medium temperature of 20 ℃ ~ +280 ℃.
