No. | Part Name | Qty | Material |
1 | Body | 1 | Carbon Steel ASTM A108 |
2 | Seat | 1 | RTFE |
3 | Ball | 1 | 304 Stainless Steel |
4 | Thrust Washer | 1 | PTFE |
5 | Packing Nut | 1 | 300 Series Stainless Steel |
6 | Stem | 1 | 304 Stainless Steel |
7 | Handle Nut | 1 | Zinc Plated Steel |
8 | Handle Washer | 1 | Zinc Plated Steel |
9 | Stem Packing | 1 | PTFE |
10 | Seat | 1 | RTFE |
11 | Retainer | 1 | Carbon Steel ASTM A108 |
12 | Handle | 1 | Zinc Plated Steel |
13 | Gland Packing | 1 | 304 Stainless Steel |
14 | Handle Sleeve | 1 | PVC |
Size | A | B | C | ØD | E |
1/4 | 1.73 | 1.24 | 2.76 | 0.20 | 0.75 |
3/8 | 1.89 | 1.28 | 3.15 | 0.28 | 0.83 |
1/2 | 2.44 | 2.22 | 4.13 | 0.35 | 1.14 |
3/4 | 2.76 | 2.34 | 4.13 | 0.49 | 1.38 |
1 | 3.39 | 2.17 | 4.45 | 0.59 | 1.61 |
1-1/4 | 3.70 | 2.99 | 5.71 | 0.79 | 2.24 |
1-1/2 | 4.02 | 3.07 | 5.71 | 0.98 | 2.24 |
2 | 4.49 | 3.27 | 7.09 | 1.26 | 2.89 |
Size | Cv | Weight(lbs.) |
1/4 | 2 | 0.2 |
3/8 | 2.5 | 0.3 |
1/2 | 5 | 0.7 |
3/4 | 10 | 1.0 |
1 | 15 | 1.5 |
1-1/4 | 30 | 3.4 |
1-1/2 | 50. | 3.2 |
2 | 70 | 5.9 |
